Gpl36W 36watt 410mm UV Light for AC HVAC Air Duct Purification 253.7nm Air Recirculation ...
The UVC GPH436T5L/HO is 48W. but the GPH436T5L is 21W. They are the same length (436mm). Why the high output lamp has the high energy? because change the diameter of the filament and add more gas in the GPH436T5L/HO lamp.
Description
We have many years of experience in Ultraviolet Lamp For School Disinfection, UV Sterilizer Machine For Home, 4 Pin UV C Tube Light. With the tenet of 'high quality, high efficiency and development', the company services for customers with advanced technology, quality and good price ofenterprises both at home and abroad. Through cooperation with universities and research institutions, we continue to improve the formula, adopt the latest production technology, and have many new products. We sticks to the path of professionalism, and continues to innovate and surpass. This way we are going to be providing you with all the knowledge needed to make the best choice. Our company is proud of its reputation for decent management style.


The UVC GPH436T5L/HO is 48W. but the GPH436T5L is 21W. They are the same length (436mm). Why the high output lamp has the high energy? because change the diameter of the filament and add more gas in the GPH436T5L/HO lamp. According to the formula Power=Current * Voltage, the same Voltage but change the current for the lamp. The power will be high. So use the high output lamp save the space for the equipment in the end.

4 PIN Single End For UV germicidal lamp | ||
| Model NO. | GPH436T5L/HO |
Overall Length | 436MM | |
Watt | 48W | |
Diameter | 15MM | |
Ultraviolet intensity at 1 meter | 120uw/cm2 | |
13W | ||
Current | 800mA | |
Liftime | 9000 hrs | |
Type | Type | Power | Diameter | Length (BF-BF) | Current | Voltage | UVC Output | Life time |
Ozone Free | Ozone | W | mm | mm | A | V | μw/cm² | H |
GPH118T5L | GPH118T5VH | 6 | 15 | 118 | 425 | 25 | 13 | 9000 |
GPH150T5L | GPH150T5VH | 8 | 15 | 150 | 425 | 27 | 20 | 9000 |
GPH212T5L | GPH212T5VH | 10 | 15 | 212 | 425 | 30 | 26 | 9000 |
GPH287T5L | GPH287T5VH | 14 | 15 | 287 | 425 | 41 | 40 | 9000 |
GPH303T5L | GPH303T5VH | 15 | 15 | 303 | 425 | 43 | 43 | 9000 |
GPH357T5L | GPH357T5VH | 17 | 15 | 357 | 425 | 51 | 57 | 9000 |
GPH436T5L | GPH436T5VH | 21 | 15 | 436 | 425 | 62 | 72 | 9000 |
GPH550T5L | GPH550T5VH | 28 | 15 | 550 | 425 | 69 | 85 | 9000 |
GPH793T5L | GPH793T5VH | 37 | 15 | 793 | 425 | 112 | 120 | 9000 |
GPH843T5L | GPH843T5VH | 40 | 15 | 843 | 425 | 120 | 135 | 9000 |
GPH1148T5L | GPH1148T5VH | 55 | 15 | 1148 | 425 | 165 | 170 | 9000 |
GPH1554T5L | GPH1554T5VH | 75 | 15 | 1554 | 425 | 220 | 220 | 9000 |
GPH1630T5L | GPH1630T5VH | 79 | 15 | 1630 | 425 | 231 | 228 | 9000 |
High Output
Type | Type | Power | Diameter | Length (BF-BF) | Current | Voltage | UVC Output | Life time |
Ozone Free | Ozone | W | mm | mm | A | V | μw/cm² | H |
GPH212T5L/HO | GPH212T5VH/HO | 18 | 15 | 212 | 800 | 23 | 50 | 9000 |
GPH287T5L/HO | GPH287T5VH/HO | 27 | 15 | 287 | 800 | 34 | 75 | 9000 |
GPH357T5L/HO | GPH357T5VH/HO | 32 | 15 | 357 | 800 | 40 | 95 | 9000 |
GPH436T5L/HO | GPH436T5VH/HO | 48 | 15 | 436 | 800 | 70 | 120 | 9000 |
GPH793T5L/HO | GPH793T5VH/HO | 72 | 15 | 793 | 800 | 90 | 210 | 9000 |
GHO36T5L | GHO36T5VH | 80 | 15 | 843 | 800 | 127 | 260 | 9000 |
GPH893T5L/HO | GPH893T5VH/HO | 90 | 15 | 893 | 800 | 135 | 270 | 9000 |
GHO64T5L | GHO64T5VH | 150 | 15 | 1554 | 800 | 220 | 400 | 9000 |
GPH846T6L/HO | GPS846T6VH/HO | 80 | 19 | 843 | 1000 | 130 | 280 | 9000 |
GPH1148T6L/HO | GPH1148T6VH/HO | 120 | 19 | 1148 | 1000 | 185 | 340 | 9000 |
GPH1554T6L/HO | GPH1554T6VH/HO | 150 | 19 | 1554 | 1000 | 230 | 400 | 9000 |









Tidro UV excels in developing innovative, custom germicidal UVC lamps to meet application specifications. We offer custom design and engineering in every area of lamp production including lamp length, diameter, ceramic bases, sockets, power, and even custom phosphor blends to achieve optimal wavelength emissions. We are recognized in the market for excellence in product design and manufacture, holding ourselves to high quality standards and following a strict quality policy as part of our ISO9001:2015 registration.
We are committed to providing ecologically sound solutions as we strive to balance environmental protection and public safety with the need for effective disinfection. We continue to develop technologies that are vital for the health of the earth’s indispensable resources such as clean air and water. With both our standard and tailor-made lamps, OEMs can maintain replacement sales within their market, offering an often-untapped source of revenue and repeat business.
Our company takes the quality as the foundation, the service first principle, produces the high quality Gpl36W 36watt 410mm UV Light for AC HVAC Air Duct Purification 253.7nm Air Recirculation ... for the user. We follow the laws of the market, conform to the trend of the times, and abide by the promise of honesty and trustworthiness. Looking forward to the future, we are full of confidence and will repay our customers with outstanding achievements.
Hot Tags: UVC 36w 254nm purification UV tube, China, suppliers, manufacturers, factory, customized, wholesale, buy, price, Germicidal Bulb For School Hotel, UV Lamp For Aquarium Disinfection, UV Light Sterilizer For Room, H Shape UV Lamp GPX7, UV Lamp Ceramic Base UVC OZONE, Germicidal UV Tube Ballast
