pH7-800-95 for TUV95W Ho Gpl95W UVC Germicidal Lamp Hight Output 40~105W 55W 60W 75W Electronic Ballast

pH7-800-95 for TUV95W Ho Gpl95W UVC Germicidal Lamp Hight Output 40~105W 55W 60W 75W Electronic Ballast

Choosing the right electronic ballast is essential as system performance depends upon the interaction between the ballast and the lamp. Germicidal UV lamps are gas discharge devices that would be inherently unstable without ballasts to restore and maintain operation. LightSources offers assistance in matching the right ballasts to your lamp.

Description

We keep the road of independent technological innovation, and we inherit the mission of the national brand, making long-term contributions to the development of the Quartz UVC U Shape Tube, Disinfection Lamps Low Pressure, Ultraviolet Lamp For School Disinfection industry. We are open-minded to listen to and accept customers' valuable opinions, devote ourselves to research and innovation, and strive to save customers' worry, time and effort. Our advanced technology products are quickly and well recognized by consumers, and we feel value for money in use, that is, we quickly turn the technical advantage into the market competitive advantage.


Ballast: 230v Nominal (198–264v AC) 50/60 Hz for GPH Lamps (212–357mm)


Input Voltage:

230v Nominal (198~264v AC)

Frequency:

50/60 Hz.

Size:

3.15" x 1.57" x .87"

Lamp Types:

GPH212T5, GPH287T5, GPH303T5, GPH357T5, TUV11W, TUV16W

Weight:

2.47 oz.

Mounting:

Slotted Mounting Tabs

Type

Size

Input Voltage

Lamp Power

Lamp Specification

RW3-425-18A

75*48*39mm

110-120V±10%

10-17W

UVC11W-UVC16W

RW5-425-40

105*60*31mm

220-240V±10%

10-40W

GPH212-843T5
G36T5

UVC36T5
CUH36W

RW5-425-40A

105*60*31mm

110-120V±10%

10-40W

GPH212-843T5

UVC11W-UVC16W

RW12-180-10

81.5*42*23.5mm

220-240V±10%

4-8W

UVC4W

UVC6W

UVC8W

RW12-180-10A

81.5*42*23.5mm

110-120V±10%

4-8W

UVC4W

UVC6W

UVC8W

RW12-425-18

81.5*42*23.5mm

220-240V±10%

10-17W

GPH287-357T5

RW12-425-18A

81.5*42*23.5mm

110-120V±10%

10-17W

GPH287-357T5

UVC16W

RW15-425-18

81.5*42*23.5mm

220-240V±10%

10-17W

GPH212-357T5

UVC11W-UVC16W

RH9-2100-320

250*108*57mm

220-270V±10%

200-320W

GPHHA1000T6L

GPHHA1554T6L

RL1-425-90

215*44*26mm

220-240V±10%

40-79W

GPH1148-1630T5

G48T5 G64T5
G67T5 UVC64T5

RL1-800-100

215*44*26mm

220-240V±10%

55-95W

GPH436-893T5HO

GHO36T5

UVC75WHO

RL11-425-40

165*38*26mm

220-270V±10%

21-40W

G36T5

GPH212-843T5L

UVC40W

TN51-425-40L

200*80*57mm

220-270V±10%

10-40W

GPH212-843T5L

UVC11W-UVC40W

TN51-800-95L

200*80*57mm

220-270V±10%

48-95W

GPH436-1063T5HO
CUH35WHO

CUH60WHO
CUH95WHO

TN2-800-2/75U

220*70*30mm

110-240V±10%

75-155W

GHO36T5L
GPH436/846T5HO
TUV PL-L35/60WHO
TUV36T5HO
GHO64T5L
GPH1554T5HO
TUV PL-L95WHO
TUV64T5HO

>>Large-scale life wastewater treatment

>>Industry wastewater treatment

>>Drinking water, village water supply

>>Purity water

>>High purity water sea water treatment

>>Center air condition

>>Large-scale ventilation duct

>>Air disinfection

>>Ultra pure water degradation TOC system

Choosing the right electronic ballast is essential as system performance depends upon the interaction between the ballast and the lamp. Germicidal UV lamps are gas discharge devices that would be inherently unstable without ballasts to restore and maintain operation. LightSources offers assistance in matching the right ballasts to your lamp.

Tidro UV is dedicated to delivering innovative UVC germicidal solutions with first-to-market lamp products and technology, striving to improve cost-efficiency with environmentally friendly practices. We follow a strict quality policy as part of our ISO9001:2015 registration and are committed to your total satisfaction.

We provide the most attentive service, such as disseminating knowledge about our pH7-800-95 for TUV95W Ho Gpl95W UVC Germicidal Lamp Hight Output 40~105W 55W 60W 75W Electronic Ballast and guiding our customers to the correct use of our products. Welcome customers from all over the world to guide us, we will serve you wholeheartedly. Our company adheres to the quality-oriented development route, strengthens scientific management, and constantly introduces products with cost-effective advantages.
