Electronics Ballast For UV Germicidal Lamp
Mains Voltage: 230VAC±10% 50/60Hz
Ambient temperture: -15~40℃
Lamp power: 2*87W
Lamp current: 425mA
Rated life: 2 years
Description
PH8-800-2/87U ballast for 75w UVC germicidal lamp
Product Detail
|
Mains Voltage |
230VAC±10% 50/60Hz |
|
Ambient temperture |
-15~40℃ |
|
Lamp power |
2*87W |
|
Lamp current |
425mA |
|
Rated life |
2 years |
|
Dimension |
185*56*38mm |
|
Type |
UV Lamp Electronic Ballast |
|
Application |
UV Germicidal Lamp |
|
Certificate |
CE |
|
Alarm |
LED indicator |
|
Product Keywords |
21~40W Ballast |
|
Type |
Size |
Input Voltage |
Lamp Power |
Lamp Specification |
|
RW3-425-18A |
75*48*39mm |
110-120V±10% |
10-17W |
UVC11W-UVC16W |
|
RW5-425-40 |
105*60*31mm |
220-240V±10% |
10-40W |
GPH212-843T5 UVC36T5 |
|
RW5-425-40A |
105*60*31mm |
110-120V±10% |
10-40W |
GPH212-843T5 UVC11W-UVC16W |
|
RW12-180-10 |
81.5*42*23.5mm |
220-240V±10% |
4-8W |
UVC4W UVC6W UVC8W |
|
RW12-180-10A |
81.5*42*23.5mm |
110-120V±10% |
4-8W |
UVC4W UVC6W UVC8W |
|
RW12-425-18 |
81.5*42*23.5mm |
220-240V±10% |
10-17W |
GPH287-357T5 |
|
RW12-425-18A |
81.5*42*23.5mm |
110-120V±10% |
10-17W |
GPH287-357T5 UVC16W |
|
RW15-425-18A |
81.5*42*23.5mm |
110-120V±10% |
10-17W |
GPH287-357T5 UVC16W |
|
RH9-2100-320 |
250*108*57mm |
220-270V±10% |
200-320W |
GPHHA1000T6L GPHHA1554T6L |
|
RL1-425-90 |
215*44*26mm |
220-240V±10% |
40-79W |
GPH1148-1630T5 G48T5 G64T5 |
|
PH1-800-100 |
215*44*26mm |
220-240V±10% |
55-95W |
GPH436-893T5HO GHO36T5 UVC75WHO |
|
RL11-425-40 |
165*38*26mm |
220-270V±10% |
21-40W |
G36T5 GPH212-843T5L UVC40W |
|
ESP51-425-40L |
200*80*57mm |
220-270V±10% |
10-40W |
GPH212-843T5L UVC11W-UVC40W |
|
TN51-800-95L |
200*80*57mm |
220-270V±10% |
48-95W |
GPH436-1063T5HO CUH60WHO |
|
TN2-800-2/75U |
220*70*30mm |
110-240V±10% |
75-155W |
GHO36T5L |
>>Large-scale life wastewater treatment
>>Industry wastewater treatment
>>Drinking water, village water supply
>>Purity water
>>High purity water sea water treatment
>>Center air condition
>>Large-scale ventilation duct
>>Air disinfection
>>Ultra pure water degradation TOC system
Life Sciences
This industry requires a high-level of water disinfection to meet USP regulations. UVC germicidal lamps quickly and effectively disinfect and sterilize the water, destroy ozone and chlorine/chloramines, and reduce TOCs to meet the strict purified water and water for injection (WFI) standards of bio-engineering, genetic and medical testing, research laboratories, nanotechnology, and pharmacology, food science, and biotechnology.
