25W UV Water Sterilizers
Model: TDUV-25
Flow rate: 6GPM
Reactor dimension: 590*63.5cm
In/outlet port: 1/2'' male
Description
25w 6gpm UV sterilizer for water treatment |
||
|
|
Model |
TDUV-25 |
|
Flow rate |
6GPM |
|
|
Reactor dimension |
590*63.5cm |
|
|
In/outlet port |
1/2'' male |
|
|
Packing size/cm |
79.5*28*47.5cm / 8 sets |
|
|
UV lamp code |
GPH565T5L |
|
|
Lamp power |
25W |
|
|
Quartz tube code |
QT5-580 |
|
|
Ballast code |
EB-G28 |
|
|
UV Water Sterilizer |
||||||
|
Model |
Flow rate/gpm |
Flow rate (L/H) |
Material |
Life (Hour) |
Lamp size (mm) |
Inlet/Outlet connect |
|
TDUV-4W |
0.3 gpm |
55 |
304ss |
9000 |
153 |
1/4 |
|
TDUV-6W |
0.5 gpm |
120 |
304ss |
9000 |
215 |
1/4 |
|
TDUV-12W |
1 gpm |
230 |
304ss |
9000 |
287 |
1/4 |
|
TDUV-16W |
2 gpm |
480 |
304ss |
9000 |
345 |
1/2 |
|
TDUV-25W |
6 gpm |
1300 |
304ss |
9000 |
565 |
1/2 |
|
TDUV-30W |
8 gpm |
1800 |
304ss |
9000 |
885 |
3/4 |
|
TDUV-35W |
10 gpm |
2270 |
304ss |
9000 |
925 |
3/4 |
|
TDUV-55W |
12 gpm |
2725 |
304ss |
9000 |
925 |
3/4 |
Q: How should I choose the UVC purification lights?
A: Usually UVC purification lights are used for indoor and it's harmful for human's eyes and skins if the UVC lights are direct. The most important thing for UVC purification light is safe. Safety UVC purification light means safe design to avoid the direct UVC light hurts humans and animals, at the same time the high UVC efficacy can really purify virus and bacteria in the air.
Q: What kind of UVC lights do you have?
A: We concentrate on UVC purification lights, at present we have surface purification lights, air purification lights and UVC safety system. The surface purification lights can combine with UVC safety system to install for hospitals, offices, schools, supermarkets and other public indoor places.
Q: Any important certificates for our markets?
A: Yes, there are some available test reports or certificate, such as SGS test report, irradiance test report, UL/cUL, FCC, TUV, PSE, CE, ROHS, Erp etc.
Q: Can your products’ label, packaging, design be customized?
A: Yes, we offer customization service on these.
